Ausführung des elektrischen Anschlusses | Schraubanschluss |
Komplettgerät mit Sockel | false |
Mit abnehmbaren Klemmen | false |
Mit LED-Anzeige | true |
Bemessungssteuerspeisespannung Us bei DC | 24 - 24 V |
Spannungsart zur Betätigung | DC |
Antrieb, Polung | gepolt |
Schaltverhalten des Antriebs | monostabil |
Anzahl der Kontakte als Öffner | 2 |
Anzahl der Kontakte als Schließer | 2 |
Anzahl der Kontakte als Wechsler | 0 |
Mit zwangsgeführten Kontakten | true |
Schutzart (IP) | IP20 |
Breite | 22,5 mm |
Höhe | 100 mm |
Tiefe | 120 mm |
3D / BIM Objekt
Download
(Stand: 27.09.2024)
|
Anschlussbild
Download
(Stand: 27.09.2024)
|
Deeplink Produktseite
Download
(Stand: 27.09.2024)
|
Flussdiagramm
Download
(Stand: 27.09.2024)
|
Produktdatenblatt
Download
(Stand: 27.09.2024)
|
Produktdatenblatt
Download
(Stand: 27.09.2024)
|
REACH-Erklärung
Download
(Stand: 27.09.2024)
|
RoHS-Erklärung
Download
(Stand: 27.09.2024)
|
Schaltbild
Download
(Stand: 27.09.2024)
|
Technische Information
Download
(Stand: 27.09.2024)
|
Verkaufsprospekt
Download
(Stand: 27.09.2024)
|
Anwendungsvideohochgeladen am 27.09.2024 |
Frage und Antwort (Q&A Video)hochgeladen am 27.09.2024 |
Produktvideohochgeladen am 27.09.2024 |
