Bemessungsdauerstrom Iu | 160 A |
Bemessungsspannung | 690 - 690 V |
Bemessungsgrenzkurzschlussausschaltstrom Icu bei 400 V, 50 Hz | 50 kA |
Einstellbereich des kurzzeitverzögerten Kurzschlussauslösers | 100 - 1000 A |
Einstellbereich des unverzögerten Kurzschlussauslösers | 100 - 1000 A |
Verlustleistung | 4,2 W |
Gerätebauart | Einbaugerät Festeinbautechnik |
Integrierter Erdschlussschutz | false |
Anschlussart Hauptstromkreis | Bolzenanschluss |
Geeignet für Hutschienenmontage | false |
Hutschienenmontage optional | false |
Anzahl der Hilfskontakte als Öffner | 0 |
Anzahl der Hilfskontakte als Schließer | 0 |
Anzahl der Hilfskontakte als Wechsler | 0 |
Mit Ausgelöstmelder | false |
Mit integriertem Unterspannungsauslöser | false |
Polzahl | 4 |
Position des Anschlusses für Hauptstromkreis | vorne |
Ausführung des Betätigungselements | Knebel |
Komplettgerät mit Schutzeinheit | true |
Motorantrieb integriert | false |
Motorantrieb optional | true |
Schutzart (IP) | IP20 |
Produktdatenblatt
Download
(Stand: 21.08.2024)
|
Sonstige
Download
(Stand: 21.08.2024)
|
Deeplink Produktseite
Download
(Stand: 21.08.2024)
|
RoHS-Erklärung
Download
(Stand: 21.08.2024)
|
REACH-Erklärung
Download
(Stand: 21.08.2024)
|
Gebrauchsanleitung
Download
(Stand: 21.08.2024)
|
EPD-Erklärung
Download
(Stand: 21.08.2024)
|
Technische Information
Download
(Stand: 21.08.2024)
|
Technische Information
Download
(Stand: 21.08.2024)
|
Maßzeichnung
Download
(Stand: 21.08.2024)
|
Maßzeichnung
Download
(Stand: 21.08.2024)
|
DOC CE-Erklärung
Download
(Stand: 21.08.2024)
|
Anschlussbild
Download
(Stand: 21.08.2024)
|
Sonstige
Download
(Stand: 21.08.2024)
|
