Netzform DC | false |
Netzform IT | false |
Netzform TN | true |
Netzform TN-C | false |
Netzform TN-C-S | true |
Netzform TN-S | true |
Netzform TT | true |
Netzform sonstige | false |
Anzahl der Leiter (ohne Erde) | 4 |
Nennableitstoßstrom (8/20) | 5 kA |
Max. Ableitstoßstrom (8/20) | 5 kA |
Nennspannung AC | 400 V |
Höchste Dauerspannung AC | 275 V |
Höchste Dauerspannung DC | 350 V |
Schutzpegel | 1,4 kV |
Schutzpegel L-N | 1,8 kV |
Schutzpegel N-PE | 1,4 kV |
Max. Überstromschutzeinrichtung Stichverdrahtung (Sicherung) | 125 A |
Max. Überstromschutzeinrichtung V-Verdrahtung (Sicherung) | 125 A |
Kurzschlussfestigkeit (Isccr) | 100 kA |
Integrierter Kurzschlussschutz | false |
Integrierte Vorsicherung | false |
Leckstromfrei | true |
Montageart | sonstige |
Baugröße | 4 TE |
Max. Leiterquerschnitt starr (ein-/mehrdrähtig) | 25 qmm |
Max. Leiterquerschnitt flexibel (feindrähtig) | 16 qmm |
Mit Fernmeldekontakt | false |
Signalisierung am Gerät | optisch |
Prüfklasse Typ 2 | true |
Schutzart (IP) | IP20 |
